Experience Limitless Speed and Security

A cost-effective, enterprise-grade 5G router built with advanced security and performance, designed to support a wide range of application use cases.

Powerful Performance for the next generation of 5G wireless connectivity

Experience the RC500, your gateway to next generation business connectivity.
From basic to advanced requirements, the RC500 empowers you to scale
effortlessly while delivering unparalleled bandwidth, ultra-low latency, and
improved communications. The RC500 is a feature-rich platform tailored for
enterprise level connectivity with lightning-fast speeds.

Reliable performance

Get 5G gigabit speeds with Qualcomm’s SDX62 chipset-based module. With an advanced RF external antenna design to provide optimal 5G performance. A single SKU for global deployment.

Private 5G support

Adding devices to your Private 5G network is no longer a hassle. Integration is as simple as plug and play. Supports NSA, SA and Private 4G/5G.

Enterprise-grade security

Guarantee safe and secure connectivity to your enterprise network, even for remote workers accessing it from anywhere in the world.

Superior Wi-Fi 6 connectivity

Dual-band Wi-Fi 6 with 2×2 MU-MIMO for up to 50 connected devices with peak speed up to 3000Mbps.

Remote device management

PhoneMDM™ streamlines remote device management with a user-friendly web interface for configuring settings, viewing diagnostics, and alerts notification. PhoneMDM™ enables the management of multiple devices from one location, saving time and resources.

Valuable

Rugged Design, Cost-effective, Multi-Carrier Support.

Security

Firewall, VPN, VLAN, WPA3, Unique Auth Key.

Practical

Simple Setup, Remotely Managed, Scalable Features.

Features & specifications

Cellular Frequency Band

5G NR | NSA | n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/70/ 71/ 75/ 76/ 77/ 78/ 79.
LTE-FDD | B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/ 66/ 71.
LTE-TDD | B34/ 38/ 39/ 40/ 41/ 42/ 43/ 48 | LAA | B46 | UMTS WCDMA | B1/ 2/ 4/ 5/ 8/ 19
GNSS | GPS/ GLONASS/ BDS/ Galileo

Cellular Features

Supports NSA and SA modes | Multi constellation GNSS receiver.
Qualcomm’s SDX62 platform | 3GPP Release 16 specification.
Enhanced features such as ultra-high bandwidth, millisecond-level latency, 5G network slicing, and ultra-reliability.
5G SA Sub-6 DL 2.4 Gbps; UL 900 Mbps | 5G NSA Sub-6 DL 3.4 Gbps; UL 550 Mbps.
LTE DL 1.6 Gbps; UL 200 Mbps | WCDMA DL 42 Mbps; UL 5.76 Mbps.

Global Support

Covers nearly all the mainstream carriers worldwide with 5G and LTE-A coverage

Key Features

1.3GHz Dual-core CPU.
4x1GB LAN Ethernet ports | 1GB WAN Ethernet port for failover and fallback feature.
Enterprise remote management service.
5G NR compact high-performance Ultra Wide band external cellular antenna.
WIFI 6 (802.11ax) | Peak speed up to 3000Mbps | 2.4GHz and 5.8GHz.
Optional Built-In GPS location service.
Optional USB to RS485, GPIOs | USB 3.0.

WiFi

MIMO Configuration: 2×2 (2-stream).
Wi-Fi Security: WPA,WPA2, WPA3.
Peak Speed: 3000Mbps.
Wi-Fi Spectral Bands: 2.4 GHz, 5 GHz.
802.11ax /802.11ac /802.11n/802.11g/802.11a/802.11b.

Network

Dual WAN | LAN DHCP config.
Auto APN Cellular Connectivity.
Cellular Network Priority | Network Band Lock Option.
Router Operations Mode | AP, LAN Repeater, Client.
Router Wireless Repeater Mode | Statice Lease.
LAN Ethernet Port Enable/Disable.

Firewall

Allow whitelist/blocklist IP.
IPsec | OpenVPN | SafeDNS.
Port Forward.
IDS Threat detect and prevent | Traffic monitoring.
Block geographic location.
Captive Portal.
VLAN | Schedule Internet Access.

Environmental

Operation Temperature -30°C to +75°C (-31°F~167°F)
Extended Temperature -40°C to 85°C (-40°F~176°F)
Relative Humidity ≤90%, non-condensation

Package Content

5G Router (RC500).
Power adapter.
4x Dual Band WiFi Antenna.
4x 5G Cellular Antenna.
1x Ethernet Cable.

Power Adapter

Input AC100 ~240V | Output 12v, 3A.
DC 5.5×2.1MM

LEDs

Power | Cellular | Internet

Interface

1 x LAN 1GB Ethernet RJ-45 port | USB 3.0 port
4x N Type Cellular Connector | 4 x N Type WiFi Connector
SIM 1 Nano SIM Card | SIM 2 Optional

Wi-Fi Wireless

Wi-Fi 6 Dual Radio | 2.4GHz & 5GHz Radio.
Enable/Disable Broadcast SSID.
Radio Transmission Power Adjustment ( 3 stage).
WPA3 | Isolate Clients.
Restrict Number of Connected Client Devices.
Guest WiFi | WiFi MAC Filtering.

Apps

Global DNS.
Rebind Protection | Rebind Localhost.
MQTT | MODBUS TCP.
Siemens S7 Client.
PCAP | GPS.

Accessories

Outdoor Antenna

5G + WIFI6 + GPS outdoor
rugged antenna

Backup UPS

12v Constant Power, 52000mAh, 115.44WH

tBox Outdoor Enclosure

All Weather, Industrial Design for IoT

Vehicle Wire Harness

DC power cale with fuse for vehicle application

Solar IoT System

Green Energy for IoT application

Remote Management

Deploy, Manage and Secure

Remote Device Management

Configure, Deploy & Manage Securely

Monitor your IoT products with end-to-end visibility for total oversight, control and centralized management with security. Experience unprecedented ease and efficiency in IoT device management. From deployment to monitoring and troubleshooting, the end-to-end cloud solution helps you achieve more with less effort.

Use Case

Local Government

With its high-speed 5G connection, the RC500 offers efficient communication and collaboration between government agencies and schools.

Business and Enterprise

Effective solution to enhance productivity and security for businesses and Enterprise with 5G and WIFI6 to support various business applications.

Mobility

Cost-effective 5G autonomous connectivity enables vehicles to stay connected. Increasing safety, efficiency on the road, and in-car experience.
